| Technical Specification | ||
| Parameter | ||
| Model Number | ||
| Communication Interface | RS485 / CAN / UART | |
| Charging Voltage | DC: CC/CV (3.2V/Cell) | DC: CC/CV (4.2V/Cell) |
| Maximum Continuous Charging Current | ||
| Maximum Continuous Discharging Current | ||
| Current Consumption in Normal Operation | ||
| Current Consumption in Sleep Operation | ||
| Balance Voltage for Single Cell | 3.5 ± 0.05V | 4.0 ± 0.05V |
| SOC Accuracy | ||
| Protection Parameters | ||
| Parameter | ||
| Overcharge Detection Voltage | 3.65 ± 0.05V | 4.25 ± 0.05V |
| Charge Overcurrent Detection Current | ||
| Discharge Overcurrent Detection Current 1 | ||
| Discharge Overcurrent Detection Current 2 | ||
| Short-Circuit Protection | YES | |
| Low Temperature Protection When Charging | 0℃ | |
| Release Temperature (Low Temperature Protection) | 5℃ | |
| Over Temperature Protection When Charging | 60℃ | |
| Release Temperature (Over Temperature Protection) | 55℃ | |
| Low Temperature Protection When Discharging | 15℃ | |
| Release Temperature (Low Temperature Protection) | 10℃ | |
| Over Temperature Protection When Discharging | 65℃ | |
| Release Temperature (Over Temperature Protection) | 55℃ | |
| Functions & Communication | ||
| Parameter | LF | LI |
| LCD Display Screen | / | |
| LED Light Board | / | |
| Bluetooth Mode | ||
| 4G | ||
| GPS | ||
| RS485 | ||
| CAN | ||
| UART | ||
| Weak Current Switch | ||
| Active Balance | / | |
| Heater | ||
| Braking Resistors | ||
| Physical & Environmental Specifications | ||
| Parameter | LF | LI |
| Size | ||
| NTC | ||
| Temperature Switch | ||
| Operating Temperature Range | -40℃ to +85℃ | |
| Storage Temperature Range | -40℃ to +125℃ | |
| Heater | ||
| Braking Resistors | ||
